[libcamera-devel] Pinephone 1.2 and libcamera

Fri Jul 1 13:22:17 CEST 2022

Found mentions to V4L2_PIX_FMT_JPEG, but no V4L2_PIX_FMT_MJPEG on
sun6i_csi.* files. Also no reference to v4l2_fourcc() function. Should I
add V4L2_PIX_FMT_MJPEG with the same settings of V4L2_PIX_FMT_JPEG?

Rafael

On 7/1/22 05:34, Rafael Diniz via libcamera-devel wrote:
> Hi Jacopo,
>
> Tried with "cam" app. Rear camera (ov5640) is taking really nice pics
> already. Front camera (gc2145) is a bit greenish. But I'd say it is a
> initial success!
>
> I'm converting the ".bin" with (libcamera says to me SBGGR8 color space):
>
> ffmpeg -f image2 -vcodec rawvideo -s $size -pix_fmt bayer_bggr8 -i
> $input $output.jpeg
>
> Some samples already converted to jpg (poor light, a bit shacky... just
> for poc):
> https://www.abradig.org.br/maemo-crazyness/back_camera.jpg
> https://www.abradig.org.br/maemo-crazyness/front_camera.jpg
>
> btw, sometimes it takes some frames for the image to "stabilize" - it is
> normal, right?
>
> I'll take a look in this V4L2_PIX_FMT_JPEG versus V4L2_PIX_FMT_MJPEG.
> Should I look at the ov5640 / gc2145 or sun6i-csi driver?
>
> Cheers,
> Rafael
>
> On 7/1/22 04:56, Jacopo Mondi wrote:
>> Hi Rafael,
>>
>> On Fri, Jul 01, 2022 at 08:24:40AM +0300, Rafael Diniz via
>> libcamera-devel wrote:
>>> Hi all,
>>>
>>> I have now both cameras in the PP listed by libcamera!
>>>
>>> Here what I used:
>>> https://github.com/rafael2k/pine64-kernel/blob/maemo/beowulf-devel/debian/patches/maemo/0245-sun6i-csi-Implement-framesize-and-frameinterva.patch
>>>
>>>
>>> https://github.com/rafael2k/pine64-kernel/blob/maemo/beowulf-devel/debian/patches/maemo/0246-sun6i-csi-Limit-formats-to-those-compatible-wi.patch
>>>
>>>
>>
>> I haven't checked how the sun6i driver looks like in mainline, but any
>> chance these patches can be upstreamed ?
>>
>>> https://github.com/rafael2k/pine64-kernel/blob/maemo/beowulf-devel/debian/patches/maemo/0247-gc2145-Add-PIXEL_RATE-HBLANK-and-VBLANK-contro.patch
>>>
>>>
>>> OV5640 driver from Jacopo branch.
>>>
>>> ./lc-compliance
>>> [0:06:52.833992694] [4053]  INFO Camera camera_manager.cpp:293 libcamera
>>> v0.0.0+3665-bb84fc6a
>>> [0:06:52.869182944] [4054]  WARN CameraSensor camera_sensor.cpp:212
>>> 'gc2145
>>> 3-003c': Recommended V4L2 control 0x009a0922 not supported
>>> [0:06:52.869387444] [4054] ERROR V4L2 v4l2_subdevice.cpp:318 'gc2145
>>> 3-003c': Unable to get rectangle 2 on pad 0: Inappropriate ioctl for
>>> device
>>> [0:06:52.869499444] [4054]  WARN CameraSensor camera_sensor.cpp:239
>>> 'gc2145
>>> 3-003c': The PixelArraySize property has been defaulted to 1600x1200
>>> [0:06:52.869568777] [4054] ERROR V4L2 v4l2_subdevice.cpp:318 'gc2145
>>> 3-003c': Unable to get rectangle 1 on pad 0: Inappropriate ioctl for
>>> device
>>> [0:06:52.869635736] [4054]  WARN CameraSensor camera_sensor.cpp:250
>>> 'gc2145
>>> 3-003c': The PixelArrayActiveAreas property has been defaulted to (0,
>>> 0)/1600x1200
>>> [0:06:52.869722027] [4054] ERROR V4L2 v4l2_subdevice.cpp:318 'gc2145
>>> 3-003c': Unable to get rectangle 0 on pad 0: Inappropriate ioctl for
>>> device
>>> [0:06:52.869798902] [4054]  WARN CameraSensor camera_sensor.cpp:258
>>> 'gc2145
>>> 3-003c': Failed to retrieve the sensor crop rectangle
>>> [0:06:52.869853194] [4054]  WARN CameraSensor camera_sensor.cpp:264
>>> 'gc2145
>>> 3-003c': The sensor kernel driver needs to be fixed
>>> [0:06:52.869935277] [4054]  WARN CameraSensor camera_sensor.cpp:266
>>> 'gc2145
>>> 3-003c': See Documentation/sensor_driver_requirements.rst in the
>>> libcamera
>>> sources for more information
>>> [0:06:52.884873194] [4054]  WARN CameraSensorProperties
>>> camera_sensor_properties.cpp:174 No static properties available for
>>> 'gc2145'
>>> [0:06:52.885049069] [4054]  WARN CameraSensorProperties
>>> camera_sensor_properties.cpp:176 Please consider updating the camera
>>> sensor
>>> properties database
>>> [0:06:52.885128986] [4054]  WARN CameraSensor camera_sensor.cpp:411
>>> 'gc2145
>>> 3-003c': Failed to retrieve the camera location
>>
>> The gc2145 driver still need some love
>> Although this should not be fatal
>>
>>> [0:06:52.889349486] [4054]  WARN CameraSensor camera_sensor.cpp:212
>>> 'ov5640
>>> 3-004c': Recommended V4L2 control 0x009a0922 not supported
>>> [0:06:52.889535069] [4054]  WARN CameraSensor camera_sensor.cpp:264
>>> 'ov5640
>>> 3-004c': The sensor kernel driver needs to be fixed
>>> [0:06:52.889602486] [4054]  WARN CameraSensor camera_sensor.cpp:266
>>> 'ov5640
>>> 3-004c': See Documentation/sensor_driver_requirements.rst in the
>>> libcamera
>>> sources for more information
>>> [0:06:52.895027736] [4054]  WARN CameraSensor camera_sensor.cpp:411
>>> 'ov5640
>>> 3-004c': Failed to retrieve the camera location
>>
>> This can be solved by updating DTS to add the 'orientation' property
>> to the camera device nodes.
>>
>>> [0:06:53.832240361] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.833094028] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.833898945] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.834654320] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.835394570] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.836180445] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.836926570] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.837657403] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.838386653] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>> [0:06:53.839121486] [4054]  WARN V4L2 v4l2_pixelformat.cpp:295
>>> Unsupported
>>> V4L2 pixel format JPEG
>>
>> Does your driver register
>>
>> #define V4L2_PIX_FMT_JPEG     v4l2_fourcc('J', 'P', 'E', 'G') /* JFIF
>> JPEG     */
>>
>> As a format for JPEG ?
>>
>> Libcamera only supports:
>>
>> #define V4L2_PIX_FMT_MJPEG    v4l2_fourcc('M', 'J', 'P', 'G') /*
>> Motion-JPEG   */
>>
>> I admit I know nothing about JPEG related standards but looking at the
>> media drivers, it seems FMT_JPEG is used more often than MJPEG.
>>
>> However libcamera only seems to support MJPEG. You might have noticed
>> libcamera uses the DRM pixelformat identifiers, and it seems that in
>> the drm_fourcc.h header we ship there's no JPEG format at all, but
>> only MJPEG. If my understanding is correct this makes sense, as the
>> MJPEG standard defines a video container format for streaming
>> JPEG-compressed frames while JFIF JPEG defines a file-encoding scheme
>> for exchanging single images. Being DRM about video output devices
>> only MJPEG applies there, so there's no "JIF/JFIF JPEG" format in
>> there.
>>
>> Now, I would not be surprised if the multiple users of FMT_JPEG in
>> drivers/media/ are actually sending MJPEG but driver developers pick
>> FMT_JPEG because of some form of cargo-cult.
>>
>> Laurent do you know more about this maybe ?
>>
>> When it comes to libcamera, for the reasons explained above, as a
>> streaming format it seems only MJPEG would make sense, while JFIF JPEG
>> could rather be used as the container when saving still images,
>> something for which we use DNG in qcam, in example.
>>
>> To remove the above error I would change your driver to report
>> FMT_MJPEG for the time being until the above doesn't get clarified.
>>
>>
>>> No camera specified, available cameras:
>>> - /base/i2c-csi/front-camera at 3c
>>> - /base/i2c-csi/rear-camera at 4c
>>>
>>
>> Good, I think you should now try to capture frames, you can try with
>> cam (which supports a DRM/KMS and an SDL output) or qcam if you have
>> Qt in your setup. Pavel was successful in this, maybe have a look at
>> the thread he started a few days before your first email.
>>
>> Cheers!
>>
>>>
>>> Cheers,
>>> Rafael
>>>
>>> On 6/30/22 05:42, Rafael Diniz via libcamera-devel wrote:
>>>> So, indeed, patches posted here are being very useful:
>>>> https://github.com/kbingham/libcamera/issues/28
>>>>
>>>> I ported the sun6i-csi patch pointed in this issue to my 5.15 branch
>>>> here:
>>>> https://github.com/rafael2k/pine64-kernel/blob/maemo/beowulf-devel/debian/patches/maemo/0245-sun6i_v4l2.patch
>>>>
>>>>
>>>>
>>>> Still doing some tests, but I think I'm getting closer.
>>>>
>>>> Rafael
>>>>
>>>> On 6/29/22 05:40, Laurent Pinchart wrote:
>>>>> Hi Rafael,
>>>>>
>>>>> On Wed, Jun 29, 2022 at 04:14:26AM -0300, Rafael Diniz wrote:
>>>>>> Thanks Laurent.
>>>>>>
>>>>>> I'm not sure if I have all the information about the PinePhone
>>>>>> hardware
>>>>>> to really implement this.
>>>>>
>>>>> It should be doable with hardware documentation. The kernel driver
>>>>> already contains information about how media bus codes map to pixel
>>>>> formats (see sun6i_csi_is_format_supported()), needed to implement
>>>>> support for IO_MC, and about the supported sizes (see the
>>>>> {MIN,MAX}_{WIDTH,HEIGHT} macros), needed to implement
>>>>> .vidioc_enum_framesizes().
>>>>>
>>>>>> On 6/28/22 17:10, Laurent Pinchart wrote:
>>>>>>> On Tue, Jun 28, 2022 at 04:22:06PM -0300, Rafael Diniz via
>>>>>>> libcamera-devel wrote:
>>>>>>>> Just adding V4L2_CAP_IO_MC to device_caps of the sun6i-csi driver
>>>>>>>> without really implementing it
>>>>>>>
>>>>>>> It can help moving one step forward, but will come to bite you back
>>>>>>> pretty soon :-)
>>>>>>>
>>>>>>>> now gives me this error (as expected I think):
>>>>>>>>
>>>>>>>> ERROR V4L2 v4l2_videodevice.cpp:1153 /dev/video2[10:cap]: Unable to
>>>>>>>> enumerate frame sizes: Inappropriate ioctl for device
>>>>>>>
>>>>>>> I've just checked, and the sun6i-csi driver is also missing
>>>>>>> support for
>>>>>>> the VIDIOC_ENUM_FRAMESIZES ioctl (.vidioc_enum_framesizes()
>>>>>>> operation in
>>>>>>> struct v4l2_ioctl_ops) :-S A bit more work seems to be needed in the
>>>>>>> driver.
>>>>>>>
>>>>>>> It makes me wonder why we list sun6i-csi as supported in the
>>>>>>> pipeline
>>>>>>> handler. Maybe libcamera has evolved to require the above since
>>>>>>> then ?
>>>>>>> We don't test on that platform internally.
>>>>>>>
>>>>>>>> On 6/28/22 07:54, Rafael Diniz via libcamera-devel wrote:
>>>>>>>>> Hi Jacopo, sorry I was not clear.
>>>>>>>>>
>>>>>>>>> I mean, support in:
>>>>>>>>> drivers/media/platform/sunxi/sun6i-csi/sun6i_video.c
>>>>>>>>> V4L2_CAP_IO_MC is not there.
>>>>>>>>>
>>>>>>>>> Rafael
>>>>>>>>>
>>>>>>>>> On 6/28/22 07:40, Jacopo Mondi wrote:
>>>>>>>>>> Hi Rafael,
>>>>>>>>>>
>>>>>>>>>> On Tue, Jun 28, 2022 at 07:26:42AM -0300, Rafael Diniz wrote:
>>>>>>>>>>> Thanks Laurent and Jacopo.
>>>>>>>>>>>
>>>>>>>>>>> This is the commit to be used as reference, right?
>>>>>>>>>>>
>>>>>>>>>>> https://git.kernel.org/pub/scm/linux/kernel/git/torvalds/linux.git/commit/?id=5fc929ae516537720d61139df92fa89ac4989c7b
>>>>>>>>>>>
>>>>>>>>>>>
>>>>>>>>>>>
>>>>>>>>>>>
>>>>>>>>>>> I took a look in different PP kernel
>>>>>>>>>>> branches, and it seems such v4l
>>>>>>>>>>> V4L2_CAP_IO_MC is not present nowhere.
>>>>>>>>>>
>>>>>>>>>> I'm not sure I got wha you mean here...
>>>>>>>>>>
>>>>>>>>>> V4L2_CAP_IO_MC has been introduced by
>>>>>>>>>> f645e6256bd1 ("media: v4l2-dev/ioctl: Add V4L2_CAP_IO_MC")
>>>>>>>>>> and it seems to be in since v5.8 ?
>>>>>>>>>>
>>>>>>>>>>>
>>>>>>>>>>> Rafael
>>>>>>>>>>>
>>>>>>>>>>> On 6/28/22 07:04, Laurent Pinchart wrote:
>>>>>>>>>>>> On Tue, Jun 28, 2022 at 12:02:52PM +0200, Jacopo Mondi wrote:
>>>>>>>>>>>>> Hi Rafael,
>>>>>>>>>>>>>
>>>>>>>>>>>>> On Tue, Jun 28, 2022 at 06:02:28AM -0300, Rafael Diniz wrote:
>>>>>>>>>>>>>> I tried to first just copy the
>>>>>>>>>>>>>> ov5640.c to my 5.15 branch, and
>>>>>>>>>>>>>> the
>>>>>>>>>>>>>> error
>>>>>>>>>>>>>> message from libcamera changed. Now I get:
>>>>>>>>>>>>>>
>>>>>>>>>>>>>> WARN CameraSensor camera_sensor.cpp:212 'ov5640 3-004c':
>>>>>>>>>>>>>> Recommended V4L2
>>>>>>>>>>>>>> control 0x009a0922 not supported
>>>>>>>>>>>>>> WARN CameraSensor camera_sensor.cpp:264 'ov5640 3-004c': The
>>>>>>>>>>>>>> sensor kernel
>>>>>>>>>>>>>> driver needs to be fixed
>>>>>>>>>>>>>> WARN CameraSensor camera_sensor.cpp:266 'ov5640 3-004c': See
>>>>>>>>>>>>>> Documentation/sensor_driver_requirements.rst in the libcamera
>>>>>>>>>>>>>> sources for
>>>>>>>>>>>>>> more information
>>>>>>>>>>>>>> WARN CameraSensor
>>>>>>>>>>>>>> camera_sensor.cpp:411 'ov5640
>>>>>>>>>>>>>> 3-004c': Failed to
>>>>>>>>>>>>>> retrieve
>>>>>>>>>>>>>> the camera location
>>>>>>>>>>>>>
>>>>>>>>>>>>> You're missing V4L2_CID_CAMERA_ORIENTATION, don't worry
>>>>>>>>>>>>> it's not
>>>>>>>>>>>>> anything fatal, simply your camera won't report it's
>>>>>>>>>>>>> orientation.
>>>>>>>>>>>>>
>>>>>>>>>>>>> The ov5640 driver is already
>>>>>>>>>>>>> instrumented to register such
>>>>>>>>>>>>> control if
>>>>>>>>>>>>> the corresponding DT property is in your DTS
>>>>>>>>>>>>>
>>>>>>>>>>>>> References:
>>>>>>>>>>>>> Documentation/devicetree/bindings/media/video-interface-devices.yaml
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>> TL;DR your DTS does not register any "orientation" property.
>>>>>>>>>>>>>
>>>>>>>>>>>>>>
>>>>>>>>>>>>>> ERROR V4L2 v4l2_videodevice.cpp:1076 /dev/video2[10:cap]:
>>>>>>>>>>>>>> Media
>>>>>>>>>>>>>> bus code
>>>>>>>>>>>>>> filtering not supported by the device
>>>>>>>>>>>>>> (this last error repeats more than 50 times ^^^^)
>>>>>>>>>>>>>>
>>>>>>>>>>>>>> ERROR SimplePipeline simple.cpp:490 No valid configuration
>>>>>>>>>>>>>> found
>>>>>>>>>>>>>
>>>>>>>>>>>>> This is not related to the sensor
>>>>>>>>>>>>> driver but rather to your receiver
>>>>>>>>>>>>> driver that does not support media bus code filtering.
>>>>>>>>>>>>>
>>>>>>>>>>>>> https://www.kernel.org/doc/html/latest/userspace-api/media/v4l/vidioc-enum-fmt.html
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>> -------------------------------------------------------------------------------
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>> V4L2_CAP_IO_MC is set (also known as an ‘MC-centric’ driver)
>>>>>>>>>>>>>
>>>>>>>>>>>>> If the mbus_code field is
>>>>>>>>>>>>> initialized to a valid (non-zero)
>>>>>>>>>>>>> media bus
>>>>>>>>>>>>> format code, then drivers shall
>>>>>>>>>>>>> restrict enumeration to only the
>>>>>>>>>>>>> image
>>>>>>>>>>>>> formats that can produce (for video
>>>>>>>>>>>>> output devices) or be produced
>>>>>>>>>>>>> from (for video capture devices)
>>>>>>>>>>>>> that media bus code. If the
>>>>>>>>>>>>> mbus_code
>>>>>>>>>>>>> is unsupported by the driver, then EINVAL shall be returned.
>>>>>>>>>>>>> -------------------------------------------------------------------------------
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>>
>>>>>>>>>>>>> libcamera requires driver to support CAP_IO_MC and
>>>>>>>>>>>>> implement the
>>>>>>>>>>>>> media-controller API for topology
>>>>>>>>>>>>> enumeration and device discovery.
>>>>>>>>>>>>>
>>>>>>>>>>>>> I asked Pavel a reference to the
>>>>>>>>>>>>> Pinephone BSP kernel to check what
>>>>>>>>>>>>> is
>>>>>>>>>>>>> the status, but looking at the error there it seems some
>>>>>>>>>>>>> work is
>>>>>>>>>>>>> required.
>>>>>>>>>>>>
>>>>>>>>>>>> It looks like thse sun6i-csi driver doesn't support
>>>>>>>>>>>> CAP_IO_MC in
>>>>>>>>>>>> mainline either.
>>>>>>>>>>>>
>>>>>>>>>>>>>> May be I'm missing something in order to backport the ov5640
>>>>>>>>>>>>>> driver to the
>>>>>>>>>>>>>> 5.15 branch?
>>>>>>>>>>>>>>
>>>>>>>>>>>>>> Thanks,
>>>>>>>>>>>>>> Rafael Diniz
>>>>>>>>>>>>>>
>>>>>>>>>>>>>> On 6/27/22 05:05, Jacopo Mondi wrote:
>>>>>>>>>>>>>>> Hi Rafael,
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>> On Mon, Jun 27, 2022 at 03:46:02AM -0300, Rafael Diniz
>>>>>>>>>>>>>>> wrote:
>>>>>>>>>>>>>>>> That is wonderful. Thanks for pointing me the OV5640
>>>>>>>>>>>>>>>> patches.
>>>>>>>>>>>>>>>> And before I
>>>>>>>>>>>>>>>> start back-porting these
>>>>>>>>>>>>>>>> patches to my 5.15
>>>>>>>>>>>>>>>> branch, is there any
>>>>>>>>>>>>>>>> git repo I
>>>>>>>>>>>>>>>> can clone just to give a first try (with these
>>>>>>>>>>>>>>>> modifications
>>>>>>>>>>>>>>>> already
>>>>>>>>>>>>>>>> inside)?
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>> I just pushed
>>>>>>>>>>>>>>> https://git.sr.ht/~jmondi_/linux/tree/jmondi/media-master/ov5640-v7
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>> which contains the last version of the 5640 patches on
>>>>>>>>>>>>>>> top of
>>>>>>>>>>>>>>> linux-media master.
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>> Thanks
>>>>>>>>>>>>>>>          j
>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>> Rafael
>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>> On 6/26/22 20:29, Laurent Pinchart wrote:
>>>>>>>>>>>>>>>>> Hi Rafael,
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>> On Fri, Jun 24, 2022 at 05:24:06AM -0300, Rafael Diniz via
>>>>>>>>>>>>>>>>> libcamera-devel wrote:
>>>>>>>>>>>>>>>>>> Hi Jocopo,
>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>> Thanks. I'm interested to know which kernel version /
>>>>>>>>>>>>>>>>>> source
>>>>>>>>>>>>>>>>>> people are
>>>>>>>>>>>>>>>>>> using to test libcamera on the PinePhone. Indeed, I
>>>>>>>>>>>>>>>>>> read all
>>>>>>>>>>>>>>>>>> the thread
>>>>>>>>>>>>>>>>>> about libcamera in PinePhone in the e-maill archives.
>>>>>>>>>>>>>>>>>> "lc-compliance"
>>>>>>>>>>>>>>>>>> says drivers I'm
>>>>>>>>>>>>>>>>>> using have no
>>>>>>>>>>>>>>>>>> proper support
>>>>>>>>>>>>>>>>>> for the features
>>>>>>>>>>>>>>>>>> needed by
>>>>>>>>>>>>>>>>>> libcamera.
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>> Those issues are
>>>>>>>>>>>>>>>>> actually not
>>>>>>>>>>>>>>>>> reported by
>>>>>>>>>>>>>>>>> lc-compliance, but
>>>>>>>>>>>>>>>>> by
>>>>>>>>>>>>>>>>> libcamera itself.
>>>>>>>>>>>>>>>>> For the OV5640
>>>>>>>>>>>>>>>>> camera sensor, the
>>>>>>>>>>>>>>>>> fixes have
>>>>>>>>>>>>>>>>> been
>>>>>>>>>>>>>>>>> posted to the
>>>>>>>>>>>>>>>>> linux-media mailing
>>>>>>>>>>>>>>>>> list (see [3], and
>>>>>>>>>>>>>>>>> in particular
>>>>>>>>>>>>>>>>> patches 15/28, 16/28 and 21/28), but not merged yet.
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>> The gc2145 driver will need more work.
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>> [3]
>>>>>>>>>>>>>>>>> https://lore.kernel.org/linux-media/20220513141548.6344-1-sakari.ailus@linux.intel.com
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>> On 6/24/22 04:46, Jacopo Mondi wrote:
>>>>>>>>>>>>>>>>>>> Hello Rafael
>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>           No
>>>>>>>>>>>>>>>>>>> longer than
>>>>>>>>>>>>>>>>>>> a few days
>>>>>>>>>>>>>>>>>>> ago Pavel
>>>>>>>>>>>>>>>>>>> sent this
>>>>>>>>>>>>>>>>>>> message
>>>>>>>>>>>>>>>>>>> https://lists.libcamera.org/pipermail/libcamera-devel/2022-June/031340.html
>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>> Hope the two of you can synch
>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>> On Thu, Jun 23, 2022 at 04:37:32PM -0300, Rafael
>>>>>>>>>>>>>>>>>>> Diniz via
>>>>>>>>>>>>>>>>>>> libcamera-devel wrote:
>>>>>>>>>>>>>>>>>>>> Hi everybody,
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> I'm working on bringing PinePhone cameras support to
>>>>>>>>>>>>>>>>>>>> Maemo-Leste system
>>>>>>>>>>>>>>>>>>>> applications, and I opted for libcamera.
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> I posted some messages here:
>>>>>>>>>>>>>>>>>>>> https://github.com/kbingham/libcamera/issues/28
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> With the kernel 5.15 with pinephone patches [1]
>>>>>>>>>>>>>>>>>>>> imported
>>>>>>>>>>>>>>>>>>>> from Mobian, I get
>>>>>>>>>>>>>>>>>>>> some
>>>>>>>>>>>>>>>>>>>> missing
>>>>>>>>>>>>>>>>>>>> features
>>>>>>>>>>>>>>>>>>>> in both
>>>>>>>>>>>>>>>>>>>> cameras
>>>>>>>>>>>>>>>>>>>> drivers
>>>>>>>>>>>>>>>>>>>> [2].
>>>>>>>>>>>>>>>>>>>> Before I
>>>>>>>>>>>>>>>>>>>> duplicate
>>>>>>>>>>>>>>>>>>>> someone's work - did anyone manage to get a kernel
>>>>>>>>>>>>>>>>>>>> which
>>>>>>>>>>>>>>>>>>>> works with current
>>>>>>>>>>>>>>>>>>>> libcamera for Pinephone 1 (not the Pro)?
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> Cheers,
>>>>>>>>>>>>>>>>>>>> Rafael
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> [1]
>>>>>>>>>>>>>>>>>>>> https://github.com/maemo-leste/pine64-kernel/tree/maemo/beowulf-devel
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> [2] ./lc-compliance
>>>>>>>>>>>>>>>>>>>>
>>>>>>>>>>>>>>>>>>>> [6:03:22.948763728] [16718] INFO Camera
>>>>>>>>>>>>>>>>>>>> camera_manager.cpp:293 libcamera v0.0.0+3665-bb84fc6a
>>>>>>>>>>>>>>>>>>>> [6:03:22.976465603] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:212 'gc2145 3-003c': Recommended V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009a0922 not supported
>>>>>>>>>>>>>>>>>>>> [6:03:22.978480561] [16719] ERROR V4L2
>>>>>>>>>>>>>>>>>>>> v4l2_subdevice.cpp:318 'gc2145 3-003c': Unable to get
>>>>>>>>>>>>>>>>>>>> rectangle 2 on pad 0: Inappropriate ioctl for device
>>>>>>>>>>>>>>>>>>>> [6:03:22.979363603] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:239 'gc2145 3-003c': The
>>>>>>>>>>>>>>>>>>>> PixelArraySize
>>>>>>>>>>>>>>>>>>>> property has been defaulted to 1600x1200
>>>>>>>>>>>>>>>>>>>> [6:03:22.979433394] [16719] ERROR V4L2
>>>>>>>>>>>>>>>>>>>> v4l2_subdevice.cpp:318 'gc2145 3-003c': Unable to get
>>>>>>>>>>>>>>>>>>>> rectangle 1 on pad 0: Inappropriate ioctl for device
>>>>>>>>>>>>>>>>>>>> [6:03:22.979499686] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:250 'gc2145 3-003c': The
>>>>>>>>>>>>>>>>>>>> PixelArrayActiveAreas property has been defaulted to
>>>>>>>>>>>>>>>>>>>> (0,
>>>>>>>>>>>>>>>>>>>> 0)/1600x1200
>>>>>>>>>>>>>>>>>>>> [6:03:22.979599769] [16719] ERROR V4L2
>>>>>>>>>>>>>>>>>>>> v4l2_subdevice.cpp:318 'gc2145 3-003c': Unable to get
>>>>>>>>>>>>>>>>>>>> rectangle 0 on pad 0: Inappropriate ioctl for device
>>>>>>>>>>>>>>>>>>>> [6:03:22.979663478] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:258 'gc2145 3-003c': Failed to
>>>>>>>>>>>>>>>>>>>> retrieve
>>>>>>>>>>>>>>>>>>>> the sensor crop rectangle
>>>>>>>>>>>>>>>>>>>> [6:03:22.979719186] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:264 'gc2145 3-003c': The sensor
>>>>>>>>>>>>>>>>>>>> kernel
>>>>>>>>>>>>>>>>>>>> driver needs to be fixed
>>>>>>>>>>>>>>>>>>>> [6:03:22.979773644] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:266 'gc2145 3-003c': See
>>>>>>>>>>>>>>>>>>>> Documentation/sensor_driver_requirements.rst in the
>>>>>>>>>>>>>>>>>>>> libcamera sources for more information
>>>>>>>>>>>>>>>>>>>> [6:03:22.979853436] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:287 'gc2145 3-003c': Mandatory V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009e0902 not available
>>>>>>>>>>>>>>>>>>>> [6:03:22.979915686] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:287 'gc2145 3-003c': Mandatory V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009f0902 not available
>>>>>>>>>>>>>>>>>>>> [6:03:22.979973686] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:287 'gc2145 3-003c': Mandatory V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009e0901 not available
>>>>>>>>>>>>>>>>>>>> [6:03:22.980280644] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:295 'gc2145 3-003c': The sensor
>>>>>>>>>>>>>>>>>>>> kernel
>>>>>>>>>>>>>>>>>>>> driver needs to be fixed
>>>>>>>>>>>>>>>>>>>> [6:03:22.980343811] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:297 'gc2145 3-003c': See
>>>>>>>>>>>>>>>>>>>> Documentation/sensor_driver_requirements.rst in the
>>>>>>>>>>>>>>>>>>>> libcamera sources for more information
>>>>>>>>>>>>>>>>>>>> [6:03:22.981451561] [16719] ERROR SimplePipeline
>>>>>>>>>>>>>>>>>>>> simple.cpp:1309 No valid pipeline for sensor 'gc2145
>>>>>>>>>>>>>>>>>>>> 3-003c', skipping
>>>>>>>>>>>>>>>>>>>> [6:03:22.986176478] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:212 'ov5640 3-004c': Recommended V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009a0922 not supported
>>>>>>>>>>>>>>>>>>>> [6:03:22.986392019] [16719] ERROR V4L2
>>>>>>>>>>>>>>>>>>>> v4l2_subdevice.cpp:318 'ov5640 3-004c': Unable to get
>>>>>>>>>>>>>>>>>>>> rectangle 2 on pad 0: Inappropriate ioctl for device
>>>>>>>>>>>>>>>>>>>> [6:03:22.986487478] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:239 'ov5640 3-004c': The
>>>>>>>>>>>>>>>>>>>> PixelArraySize
>>>>>>>>>>>>>>>>>>>> property has been defaulted to 2592x1944
>>>>>>>>>>>>>>>>>>>> [6:03:22.986555228] [16719] ERROR V4L2
>>>>>>>>>>>>>>>>>>>> v4l2_subdevice.cpp:318 'ov5640 3-004c': Unable to get
>>>>>>>>>>>>>>>>>>>> rectangle 1 on pad 0: Inappropriate ioctl for device
>>>>>>>>>>>>>>>>>>>> [6:03:22.986618769] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:250 'ov5640 3-004c': The
>>>>>>>>>>>>>>>>>>>> PixelArrayActiveAreas property has been defaulted to
>>>>>>>>>>>>>>>>>>>> (0,
>>>>>>>>>>>>>>>>>>>> 0)/2592x1944
>>>>>>>>>>>>>>>>>>>> [6:03:22.986690769] [16719] ERROR V4L2
>>>>>>>>>>>>>>>>>>>> v4l2_subdevice.cpp:318 'ov5640 3-004c': Unable to get
>>>>>>>>>>>>>>>>>>>> rectangle 0 on pad 0: Inappropriate ioctl for device
>>>>>>>>>>>>>>>>>>>> [6:03:22.986751686] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:258 'ov5640 3-004c': Failed to
>>>>>>>>>>>>>>>>>>>> retrieve
>>>>>>>>>>>>>>>>>>>> the sensor crop rectangle
>>>>>>>>>>>>>>>>>>>> [6:03:22.986807353] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:264 'ov5640 3-004c': The sensor
>>>>>>>>>>>>>>>>>>>> kernel
>>>>>>>>>>>>>>>>>>>> driver needs to be fixed
>>>>>>>>>>>>>>>>>>>> [6:03:22.988926894] [16719] WARN CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:266 'ov5640 3-004c': See
>>>>>>>>>>>>>>>>>>>> Documentation/sensor_driver_requirements.rst in the
>>>>>>>>>>>>>>>>>>>> libcamera sources for more information
>>>>>>>>>>>>>>>>>>>> [6:03:22.990680353] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:287 'ov5640 3-004c': Mandatory V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009e0902 not available
>>>>>>>>>>>>>>>>>>>> [6:03:22.990761353] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:287 'ov5640 3-004c': Mandatory V4L2
>>>>>>>>>>>>>>>>>>>> control 0x009e0901 not available
>>>>>>>>>>>>>>>>>>>> [6:03:22.990816561] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:295 'ov5640 3-004c': The sensor
>>>>>>>>>>>>>>>>>>>> kernel
>>>>>>>>>>>>>>>>>>>> driver needs to be fixed
>>>>>>>>>>>>>>>>>>>> [6:03:22.990869519] [16719] ERROR CameraSensor
>>>>>>>>>>>>>>>>>>>> camera_sensor.cpp:297 'ov5640 3-004c': See
>>>>>>>>>>>>>>>>>>>> Documentation/sensor_driver_requirements.rst in the
>>>>>>>>>>>>>>>>>>>> libcamera sources for more information
>>>>>>>>>>>>>>>>>>>> [6:03:22.991348436] [16719] ERROR SimplePipeline
>>>>>>>>>>>>>>>>>>>> simple.cpp:1309 No valid pipeline for sensor 'ov5640
>>>>>>>>>>>>>>>>>>>> 3-004c', skipping
>>>>>
>>
>>
>>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: OpenPGP_signature
Type: application/pgp-signature
Size: 840 bytes
Desc: OpenPGP digital signature
URL: <https://lists.libcamera.org/pipermail/libcamera-devel/attachments/20220701/f7024c59/attachment.sig>
